PLANNING

GUIDE

Web: http://www.Dacor.com

Corporate Phone: 800-793-0093

Specifications are subject to change without notice.

See installation instructions for additional details.

4.2

36”, 48” Wide,

Epicure™ Gas Cooktops

ESG366, ESG486

2/2

22"

(559mm)

3 1/2"

(89mm)

1 1/8"

(286mm)

5/8"

(16mm)

ESG366: 35 7/8" (911mm)

ESG486: 47 7/8" (1216mm)

ESG366: 34 3/4" (883mm)

ESG486: 46" (1168mm)

Non-combustible

rear wall

C

L

22" (559mm)

3" (76mm) Typical

ESG366: 5/8" (16mm)

ESG486: 1” (25mm)

ESG366:

17 3/8" (441mm)

ESG486:

23" (584mm)

ESG366:

17 3/8" (441mm)

ESG486:

23" (584mm)

ESG366:

36" (914mm)

ESG486:

48" (1219mm)

Countertop

CoUNtErtoP PrEPArAtIoN

NoN-CombUStIbLE rEAr WALL

Cutout for gas and electrical

locations

C L

Non-combustible

rear wall

CL

Drill two 1/2" (13mm) holes through

support shelf for cooktop mounting bolts

ESG366

16 5/8" (422mm)

ESG486

20 13/16" (529mm)

ESG366

16 5/8" (422mm)

ESG486

20 13/16" (529mm)

8" (203mm)

6" (152mm)

24" (610mm)

12 9/16"

(319mm)

bASE CAbINEt PrEPArAtIoN

NoN-CombUStIbLE rEAr WALL

toP VIEW

Combustible

rear wall

material

26 1/2" (673mm)

To bullnose

27" (686mm)

To knob

7 3/4" (197mm)

Top of

finished

counter

1" (25mm)

Minimum

Cooktop

platform

2 1/2" (64mm)

Min. to combustible surface

Combustible

rear wall

material

Optional Stainless Steel

Dacor Backsplash

ESG366: AEB3609 or AEB3612

ESG486: AEB4809 or AEB4812

oVErALL DImENSIoNS CLEArANCE

to CombUStIbLE rEAr WALL

21 3/8"

(543mm)

28 3/16"

(716mm)

5/8" (16mm)

2 Places

ESG366 - 36" (914mm)

ESG486 - 48" (1219mm)

ESG366 -33 7/8" (860mm)

ESG486 - 43 1/2" (1105mm)

3" (76mm)

Backsplash

Max.3/4" (19mm)

1/4" (6mm)

Min. flat ledge

Vertical

non-combustible

surface rear wall

2 13/16"

(71mm)

7/16" (11mm) ESG366

1 5/8” (41mm) ESG486

CUtoUt DImENSIoNS WIth

CoUNtErtoP VENt

Revised

02/29/08
