Chapter 4
MIL-3200X Series of FastPort Print Servers 4-3
F
A
S
T
M
A
N
A
G
E
b. The devices will now appear on Map 1 as “thumbnails,”
which represents each SNMP device.
c. Double-click on a thumbnail to display a full-screen
image of that particular SNMP device (see Figure 4-2).
• FastPort PrintServer Mgr. Icon:
a. Also start the software by double-clicking on the
FastPort PrintServer Mgr . icon.
b. Enter the IP Address of the device.
c. A full-screen image of that device appears (Figure 4-2).
4.3 MIL-3200X FastPort Graphical Icon
The following appears when the MIL-3200X is retrieved:
Figure 4-2. MIL-3200X Graphical Icon
Hot Spot
Pull-Down
Menus
