12

Section 6: Technical Specifications

File Formats

Audio

MP3, , 32Kb/s - 384Kb/s


JPG BMP TIFF PNG GIF

Video

RM/RMBV, 1.6Mb/s, 1024*576

Video

MP4: avi, Divx3-6, Xvid 4.5Mb/s, 720*576
DVD: vob, mpeg; 10Mb/s, 720*576
VCD: DAT, MPG, MPEG

Subtitles *.TXT,*.PSB,*.SMI,*.SRT,*.SUB,*.ASS,*.SSA

Input Ports

Disk file
system

FAT16, FAT32, NTFS

Cards SD/MMC/MS


Output Ports

2 USB Ports One usb2.0 high speed HOST port, maximum

current output 1A/5V, can connect directly with
portable HDD, no external power supply is needed,
hot-plugging is ok;

the other USB client Port is to

connect with PC.

Audio Stereo

output

Video Composite:

PAL/NTSC,

Component: 720p High Resolution output

Remote Range 6M
Power data

Video S/N≥55dB
Audio

S/N≥85dB

Power
supply

Input voltage 12VDC, Power consumption: <5W,
standard power supply 12V/1A
