4-Port DVI Switch with Audio & Serial Control

12

ASCII ‘P’ or ‘p’ (Hex 50/70 or Decimal 80/112)

Selects the Video Input priority.

A message is displayed in the format of:

Video X priority is [Y] (1-4]?

Where ‘X’ is the video input (1-4) and ‘Y’ is the current

priority (1-4).

The user must respond within 20 seconds and with values

in the range of 1-4 or the error message:

Invalid input! Please select ‘Priority’ again

will be displayed.

If ‘0’ is input, the message No change was made will be

displayed.

If the priority values are set to equal values, the first input

with an active Video signal will be displayed.

ASCII ‘B’ or ‘b’ (Hex 42/62 or Decimal 66/98)

Blanks the output.

The device will respond with: Blank mode selected

When the output is blanked, only the color intensities of the

output are reduced to zero. The unit still operates in a normal

fashion and sync signals are still routed to the output. The

audio output is muted.

ASCII ‘U’ or ‘u’ (Hex 55/75 or Decimal 85/117)

Un-blanks the output.

The device will respond with: Unblank mode selected

ASCII ‘E’ or ‘e’ (Hex 45/65 or Decimal 69/101)

Causes the output signal equalization for long cabling to be

enabled.

The device will respond with: Boost enabled
