HDMI Video Splitter, 2-Channel
3
5.0 Cascading (daisy-chaining) to expand # of outputs
You can use either output (#1 or #2) to connect the splitter to another SP-HDMI-2A to
expand the # of outputs. This can be done to a maximum of 3 levels deep.
6.0 Contacting Hall Research and Shipping/Packaging
Contact the Hall Research Technical Support Department at 714-641-6607, via email or
web.
Before you do, make a record of the history of the problem.
We will be able to provide more efficient and accurate assistance if you have a complete
description.
If you need to ship your converter for repair, make sure to get a Return Material
Authorization (RMA) number first.
7.0 Specifications
Bandwidth 2.25 Gbps (Giga bits / second) (Single Link)
Resolutions Output resolution is the same as input resolution.
Supported PC Resolutions
VGA - SVGA – XGA – SXGA – UXGA (1600x1200)
Supported Component (YPbPr) Resolutions
480i - 480p - 720p - 1080i - 1080p
Input Port 1x HDMI Female Locking Connector (Type A)
Output Ports 2x HDMI Female Locking Connector (Type A)
Temperature Operating: 32 to 122°F (0 to 50°C);
Storage: –40 to +185°F (–40 to +85°C)
MTBF 95,000 hours (calculated estimate)
Power From utility-power (mains) outlet through included external power
supply. Voltage: 5 V DC Center-Positive >= 1000 mA
Size 1.0" High x 5.0" Wide x 3.0" Deep
Weight 1.1 lbs (17 Ounces)
