Model 200A
3
3. Package Contents
 Splitter enclosure
 Input cables (6ft VGA and 3.5mm Stereo audio)
 Power adapter (6 vDC, 300mA)
4. Installation
Step 1 . Turn all the equipment off and disconnect all cables
Step 2 . Using the cables included, connect a video source to the
video input, and audio source to the 3.5mm jack
Step 3 .
Plug video
OUTPUT 1 and 2 to LCD, projector, etc. and
audio to powered speakers or other audio devices
Step 4 .
Make sure the
EDID SOURCE switch on the unit is set
appropriately (default =
OUTPUT 1)
Step 5 . Power up the LCDs and then the PC
Step 6 .
If the green light on the box (close to
PWR connector) is
not on, the video source is not providing enough power to
operate the unit. In this case attach the supplied power
adapter to the unit
5. Specifications
Video
Connectors Input and Outputs: HD15 female
Coupling: DC
Max Signal Level: 1 v p-p
Bandwidth: DC to 500 MHz
Input impedance: 75 ohms on RGB, 5K ohms on H,V
Audio
Connectors Input and Outputs: 3.5mm (mini-stereo)
Coupling: AC,
Max Signal Level: 2 v p-p
Bandwidth: 10 Hz to 20 KHz
Input impedance: 5K ohms
Dimensions W x D x H: 4 ¼ x 2 ¾ x 1 ¼ inch
Temperature.
Storage: - 40° to + 158°F (-40° to + 70°C)
Operating: + 32° to + 122°F (0° to + 50°C)
Power 6 vDC, 300mA
