Golden Blount Precision Flame Burner - Manual (Page 16)

16
PARTS LIST
Ref No. Part Number Description
1 PF-BH20 Burner Housing 20"
1 PF-BH24 Burner Housing 24"
1 PF-BH30 Burner Housing 30"
2 PF-LBS Left Burner Shield
3 VF-Ignitor Piezo Ignitor
4 PF-B20 Burner 20"
4 PF-B24 Burner 24"
4 PF-B30 Burner 30"
5 PF-RBS Right Burner Shield
6 PF-VLVRRN Valve RR Model(NAT)
6 PF-VLVRRL Valve RR Model(LP)
7 PF-VBRR Valve Bracket RR Model
8 ODS-NG ODS Pilot Nat
8 ODS-PL ODS Pilot LP
NS ODS-REG-LP ODS Pilot Regulator LP
NS ODS-REG-NAT ODS Pilot Regulator NAT
NS RV20NG Inlet Regulator NAT
NS RV20LP Inlet Regulator LP
NS PF-IGW20 Ignitor Wire 20"
NS PF-IGW24 Ignitor Wire 24"
NS PF-IGW30 Ignitor Wire 30"
(NS- “Not Shown”)
Ref No. Part Number Description
NS PF-BO20N Burner Orifice 20" NAT
NS PF-BO24N Burner Orifice 24" NAT
NS PF-BO30N Burner Orifice 30" NAT
NS PF-BO20L Burner Orifice 20" LP
NS PF-BO24L Burner Orifice 24" LP
NS PF-BO30L Burner Orifice 30" LP
NS PF-BT20RR Tubing (Valve to Burner) 20" RR
NS PF-BT24RR Tubing (Valve to Burner) 24" RR
NS PF-BT30RR Tubing (Valve to Burner) 30" RR
NS PF-PT20RR Tubing (Valve to Pilot) 20" RR
NS PF-PT24RR Tubing (Valve to Pilot) 24" RR
NS PF-PT30RR Tubing (Valve to Pilot) 30" RR
NS DC Damper Clamp
NS BLK-CIN-8# Lava Rock
NS PF-EMB20 Glowing Embers 20"
NS PF-EMB24 Glowing Embers 24"
NS PF-EMB30 Glowing Embers 30"
NS AC Aluminum Connector
NS BRS-ELBOW Gas Connection Elbow
HOW TO ORDER REPAIR PARTS
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to their service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equip-
ment. Then determine the Part Number (not the Index Number) and the description of each part from the following appropriate illustration
and list. Be sure to give all this information.
Appliance Model Number ___________________________________ Part Description _____________________________________
Appliance Serial Number ___________________________________ Part Number________________________________________
Type of Gas (Propane or Natural)_____________________________
