Go Power! Smart Charger
Owner’s Manual
4
• Ignition protection
• Output short circuit protection over power protection
• Switch mode technology
• Easy to read LED for system status
• Compact size, light weight
2.1 Battery Charging Curve
2.2 Electrical Performance
Specification Technical Data
Model No GPSC-12-10A
Power Watt 160 W
Input Voltage 100-240 VAC / 50~60 Hz (Automatic Switching)
Power Factor PF: 0.98
Nominal Voltage 12 VDC
Bulk Voltage 14.4 VDC
Float Voltage 13.65 V DC
Output Current 10 A Max.
Safety UL 1236, CE, TUV, Pending
Battery Type Wet Acid or Bulk Rating >14.3V (usually non sealed)
EMC
FCC Class A EN55022: 1994/A1: 1995/A5: 1997
EN61000-3-2: 2000, EN61000-3-3: 1995 and EN55024: 1998
Dimensions 210 (L) x 85 (W) x 50 (H) mm / 8.26 (L) x 3.34 (W) x 1.96 (H) Inch
Weight 0.9 kg. / 1.8 lbs
IU Charging Characteristic
