Go Power! GP-SW1600 - Manual (Page 4)

GPSW-600/1500
___________________________________________________________
4
2.2 600 W Inverter
SPECIFICATIONS GPSW-600 (12V) GPSW-600 (24V)
Continuous Output Power 600 W
Surge Rating 860 W
Output Waveform Pure Sine Wave <3% THD
Output Voltage ± 5% 115 VAC RMS
Input Voltage 10.5– 15 VDC 21.0-30.0
Efficiency 85-92 %
No Load Current Draw / Powersave 0.90 A 0.50 A
Protection
Overload, Short Circuit, Reverse Polarity (Fuse),
Over/Under Input Voltage, Over Temperature
Low Battery Alarm ± 2% 10.7 V 21.4 V
Low Battery Shut-Down ± 2% 10.3 V 20.6 V
Operating Temperature Range 0 - 40ºC / 32ºF - 104ºF
Storage Temperature Range -30ºC - 70ºC / -22ºF - 158ºF
Cooling Thermostatically Controlled Fan
AC Receptacle Dual GFCI
Remote Port Option Yes
Dimensions (L x W x H) in mm 295 x 180 x 72
Dimensions (L x W x H) in inches 11.6 x 7.1 x 2.8
Weight 2.7 kg / 5.9 lbs
Warranty 2 Years
Inverter Install Kits GP-DC-KIT2
UPC 8-39085-00007-6 8-39085-00018-2
