可充电电池
型号: 16340
充电器
Rechargeable Battery
Type:16340
G3云台手持件安装说明书
G3 Steadycam Installation Instructions
更多相关信息可访问飞宇科技官方网站：
www.feiyu-tech.com
特性参数：
TECH SPEC
Min-working
voltage Standard working
voltage Max-working
voltage Remark
Working Voltage 7.0V
7.0V
12.0V
12.0V
17.0V
17.0V
2S~4S LIPO
2S~4S LIPO
Static attitude
tracking accuracy
±0.01°
±0.01°
±0.2°
±0.04°
±0.04°
Motion attitude
tracking accuracy
±0.1°
±0.1°
±0.2° ±0.5°
±0.5°
Overload
protection
0.8A
0.8A
Overload
protection time
600s
600s
After overloaded 600s,
Gimbal will stop working
automatically.
Max-torque
response time
330us
330us
Controlled pitch
angle accuracy
+ 45°
0° - 90°
Weight
Pitching Angle
control rate
10°/S
10°/S
128g
Tech Specification：
项目 最小 标准 最大 备注
工作电压
静止姿态跟踪精度
运动姿态跟踪精度
电机过载电流保护
电机过载保护时间
电机输出最大力矩
响应时间
俯仰角可转动角度
俯仰角控制速率
横滚角度可转动角度
重量 128g
- 45°
- 45°
+ 45°
+ 45°
+ 35° - 90° 0°
0°
0°
电机过载600s后自动停止工
作
Controlled Roll
Angle Accuracy
35°
90°
地平面
45° 45°
横滚轴与地平面夹角不可超过45°
按Down
按Up
Push Up
Push Down
按Down
按Up
Push Up
Push Down
The angle between the roll motor and the vertical of the
ground should be less than 45°
Horizon
可以通过按钮（UP,DOWN)来调
整俯仰角。
Please visit the official website of
Feiyu-tech to get related information :
www.feiyu-tech.com
You can adjust the pitch angle by
the button （UP,DOWN)
不含电池和相机
“UP”和”DOWN”两个按钮同时按下3秒，云台横滚电机后面的指示灯红灯常亮，进入横滚调整模式。
这时通过按钮可以调整云台的横滚角，调整完毕后，同时按下“UP”和”DOWN”两个按钮3秒，红色指示
灯熄灭，退出横滚角调整模式。 8°
8°
The gyroscope need to make initialization when in following several situation : (1) When the gimbal activate the level angle have a deviation ;
(2) The gimbal has not been used for a long time; (3) There is a change in environmental temperature of over 20 degrees;
Process of gyro reset : Firstly placed the gimbal on a table and keep static ,then power on the gimbal and wait for the gimbal activate. After about 10second the
gimbal begin working , at this time the gyroscope initialization is complete.
下面几种情况需要进行陀螺仪初始化: (1) 云台启动水平角度上有偏差。 (2) 如果长时间不使用。 (3) 或者温度变化超过20度。
初始化过程如下：先把云台静止放置在桌面上，然后打开电源开关，等待云台启动。大约10 秒后云台工作，陀螺仪初始化完成。
Press “UP” and “DOWN” buttons at the same time for 3 second, the indicator light at the
back of roll motor will bright red light. This will enter the roll adjustment mode. You can adjust the
roll angle by press “UP” or “DOWN” button (The adjustable range : -8° to + 8°).After finish the
adjustment ,you can press “UP” and “DOWN” buttons at the same time for 3 second, the red
indicator light will turn off then exit the roll adjustment mode.
Containing no battery &
camera
Charger
Input:DC 5V Min 800mA
Output: DC 4.2V
WARNING:
To prevent it from fire or moisture.
To reduce the risk of electronic shock.
Do not remove cover (or back plate).
If any parts need repair, consult an
authorized service dealer.
为了防止火灾或受潮，
以及减少触电的危险，
请不要打开护盖。
如有零部件需维修, 请咨询授权
服务代理商。
输入: DC 5V Min 800mA
输出: DC4.2V
