FeiYu Tech FY-G4 3-Axis Handheld Gimbal For Smartphone - Manual (Page 2)

7
6
9
11
10
Working Voltage
Static Attitude Tracking Accuracy
Motion Attitude Tracking Accuracy
Overload Current Protection
Pitch Angle
Roll Angle
Heading Angle
Heading Angle
Pitch Following Rate
Heading Following Rate
Size
Weight
Gimbal In Static Mode
Motor Overload<2G
Handheld In Horizontal
Handheld In Horizontal (The angle
maybe vary from different smartphone)
Handheld In Vertical
Without Batteries & Smartphone
6.0V
0.01
0.1
-160（Down）
-50
-160（Left）
-50
2°/ Sec
3°/ Sec
290g
8.4V
0.02
0.2
800mA
0（Horizontal）
0（Horizontal）
17.0V
0.05
0.5
+160（Up）
+50
+160
+50
75°/ Sec
150°/ Sec
Input: DC 5V Min 800mA
Output: DC 4.2V
Type: 16340/18350
USB Mini USB
The USB Mini terminal of the USB cable
plug into the Micro interface on the charger , and the USB
terminal plug to the power adapter, then connect to the
EN Connector according to needed .
Remove the batteries, the USB Mini
terminal insert to the function interface on the gimbal and the USB
terminal insert to the USB connector then connect to the computer
for firmware upgrade or parameters configuration (Please
connect the USB cable to the computer with the USB connector,
otherwise the interface of the computer will be damaged ).
Ample buttons can realize the adjustment of
heading & pitch angle, mode switching etc.
Extend the capacity space for battery to
make the runtime longer.
Spiral design of the extension bar can be
perfect combination with G4 power switch；
Extended length is optional, it will help to
enjoy a different visual easily.
Please refer to following method to proper
usage, otherwise it may cause damage to
the device itself and other equipment.
!
1. Install the smartphone properly.
2. Gimbal placed on stationary flat and keep motionless.
3. Power on the Gimbal.
4. The Gimbal is activate and it will initialize
automatically. Pick up the Gimbal to work normally.
FY-G4 handheld gimbal for smartphone is an excellent camera stabilizer,
lightweight and portable. Prohibit any user for any illegal purpose. Users will be
responsible for all behavior of purchase and use products.
The Guilin Feiyu Electronic Technology Co. and our associates are not responsible
for any damages or liabilities caused by the use of this product.
For any unknown sources or using, we will not be any service.
Feiyu Tech reserves the right to amend this manual and the terms and conditions
of use the gimbal at any time.
With the special designed switch, the extension bar can be added directly. Allows to shoot the distance
images more easily. Special design allows for flexible extension.
Please visit the official website of Feiyu Tech
to get related information:
www.feiyu-tech.com
Type: 18350
ATTENTION
1. After power on, the angle of pitch is not level with the horizon line.
2. After power on, the angle of roll is not parallel with the horizon line.
3. When the gimbal is in heading static, the angle of heading moves frequently.
Function Interface Expansion
Function
Button
Direction
Button
Connect remote control to Gimbal in Mini port,
then you can realize control the working
mode and angle by remote control.
Note: The remote control is optional.
8
350mm
Φ23mm
G4 Battery extender contents:
G4 Battery Extender Connection Picture
Input: AC 100V-240V
Output: DC 4.2V
Type: 18650
Type: 18650
Handheld
Battery
Extender
Handheld
Accessory
Power
Switch
Width 38mm / Height 250mm / Length 93mm
FEIYU-EN-1
Suitable for iPhone6 / 5C / 5S / 5 / 4S / 4 and similar ones.
G4 Handheld Gimbal For Smartphone
