9
Getting Started
（ continued）
Remote Control Bracket
Install the bracket on the bottom of the T7UC in the slots
provided.
Slide the remote control in the bracket when not in use
just like figure shows.
3. Installing the unit under a cabinet
Step:
1. When you open all of the speakers, LCD screen
and wire box, the volume of the unit will reach
470*285*220 mm. Before installation, please make
sure it has enough room for operating where under
the cabinet.
2. Fix up the mounting template to the soleplate of
cabinet.
3. Drill four 5.5-6mm diameter holes through the
location holes.
4. Use the screws to install the unit to the bottom of
the cabinet, aiming at the holes in the top of unit.
Note: If the board of cabinet is too thick to tight the
screws up, please add 4 mount spacers between unit
and cabinet.
