MINIMUM ORDER ........................................................................... $10.00
BARRACUD
BARRACUD
BARRACUD
BARRACUD
BARRACUDA P
A P
A P
A P
A PARTS LIST
ARTS LIST
ARTS LIST
ARTS LIST
ARTS LIST
POWERHEAD PARTS
Part #
Description
Qty.
60G70
Toggle Switch
1
8905I
Throttle Control Rod
1
8906
Throttle Control, TC-300 engine
1
8910T2
HandleBar, w/throttle mounting tab
1
8912
44T Gear
1
8913
Output Shaft, 7/8"
1
8915
Dowel Pin, 1/4" x 1/2", hardened steel
1
8916
Clutch Drum & 7T Pinion Gear
1
8918
Washer-Clutch, hardened steel
1
8919
Gasket
1
8920
Centrifugal Clutch Rotor
1
8922
Ball Bearing
3
8923
Ball Bearing
2
8924
Snap Ring
3
8929
Bolt-SHCS, 1/4-20 x 1-1/2"
2
(gear case bottom to gear case top)
8931F
Bolt-SHCS, 1/4-20 x 2", full thread
4
(gear case to handlebar plate)
8932
Nut-Hex, 1/4-20 Keps
4
89382
Gear Case Top
1
8939
Gear Case Bottom
1
893BT
Gas Tank, clear
1
89TRAN2
Complete Transmission
1
9214
48T Gear & 10T Pinion Gear , one piece unit
1
GCA1
Gas Cap
1
ILBL8903B Decal, Barracuda, serialized
1
LBL891F
Decal, Barracuda, auger flight
1
LBLBPE
Decal, Eskimo, blade protector
1
LBLESKS
Decal, Eskimo oval, auger stem & handlebar plate
2
MG8900
Muffler Guard (not shown)
1
S1011
Bolt-SHCS, 1/4-20 x 3/4"
4
(handlebar plate to engine)
TC300
Gas Engine, 2-hp Tecumseh
1
POWER AUGER PARTS
Part #
Description
Qty.
232A
Blade Protector, fits 6”-8" quantum auger
1
2320A
Blade Protector, fits 6”-8” turbo auger
1
233A
Blade Protector, fits 9” & 10" quantum
1
53606
Nut, #10, nyloc
1
63387
Lockwasher, 5mm
4
8651
Strap, Blade Protector
1
8955
Auger Bolt-SHCS, 3/8-16 x 1-1/4"
1
(auger to powerhead)
90129
Point Replacement Assembly
1
90136
Bolt, #10-24 x 1-1/4” stainless
1
90165
Point Holder
1
90166
Point
1
BB6
Ice Blades, 6" TurboCut
2
BB8
Ice Blades, 8" TurboCut
2
BR6N
Ice Auger, 6" Turbo
1
BR8N
Ice Auger, 8" Turbo
1
IB5810
Bolt, 5mm x 0.8 x 10mm, (turbo ice blade to auger)
4
IB5816
Bolt, 5mm x 0.8 x 16mm, (ice blade to auger)
4
IN58
Nut, 5mm x 0.8 nyloc, (ice blade to auger)
4
QB8
Ice Blades, 8" Quantum, set of two
1
QB9
Ice Blades, 9" Quantum, set of two
1
QB10
Ice Blades, 10" Quantum, set of two
1
QT8N
Ice Auger, 8" Quantum
1
QT9N
Ice Auger, 9" Quantum
1
QT10N
Ice Auger, 10" Quantum
1
ACCESSORIES
EXT6
Depth Extension, 6"
EXT12
Depth Extension, 12"
EXT18
Depth Extension, 18"
