MINIMUM ORDER ........................................................................... $10.00
POWERHEAD PARTS
Part #
Description
Qty.
1402
Bolt-SHCS, 5/16-18 x 1-1/4"
4
(mount ring to engine)
60G70
Toggle Switch
1
8912
44T Gear
2
8913
Output Shaft, 7/8"
1
8915
Dowel Pin, 1/4" x 1/2", hardened steel
2
8919
Gasket
1
8922
Ball Bearing
3
8923
Ball Bearing
2
8924
Snap Ring
3
8929
Bolt-SHCS, 1/4-20 x 1-1/2"
2
(gear case bottom to gear case top)
8931F
Bolt-SHCS, 1/4-20 x 2", full thread
4
(gear case to handlebar plate)
8932
Nut-Hex, 1/4-20 Keps
4
8939
Gear Case Bottom
1
9005
Throttle Control Rod
1
9005A
Throttle Control Twist
1
9010
Handlebar
1
9016
Clutch Drum, 3" threaded
1
9017
12T Pinion Gear, threaded
1
9020
Centrifugal Clutch Rotor
1
9037K
Mount Ring
1
(handlebar to gear case top)
9038
Gear Case Top
1
90TRANP
Complete Transmission
1
9214A
10T Pinion Gear
1
AV520
Gas Engine, 3-hp Tecumseh
1
GCA1
Gas Cap
1
GT3HP
Gas Tank, black
1
LBL891F
Decal, Barracuda, auger flight
1
LBL9003B
Decal, Barracuda Plus, serialized
1
LBLBPE
Decal, Blade Protector, Eskimo
1
LBLESKS
Decal, Eskimo oval, auger stem & handlebar plate
2
POWER AUGER PARTS
Part #
Description
Qty.
232A
Blade Protector, fits 6”-8" quantum auger
1
2320A
Blade Protector, fits 6”-8” turbo auger
1
233A
Blade Protector, fits 9” & 10" quantum
1
53606
Nut, #10, nyloc
1
63387
Lockwasher, 5mm
4
8651
Strap, Blade Protector
1
8955
Auger Bolt-SHCS, 3/8-16 x 1-1/4"
1
(auger to powerhead)
90129
Point Replacement Assembly
1
90136
Bolt, #10-24 x 1-1/4” stainless
1
90165
Point Holder
1
90166
Point
1
BB8
Ice Blades, 8" TurboCut
2
BR8N
Ice Auger, 8" Turbo
1
IB5810
Bolt, 5mm x 0.8 x 10mm, (turbo ice blade to auger)
4
IB5816
Bolt, 5mm x 0.8 x 16mm, (ice blade to auger)
4
IN58
Nut, 5mm x 0.8 nyloc, (ice blade to auger)
4
QB8
Ice Blades, 8" Quantum, set of two
1
QB9
Ice Blades, 9" Quantum, set of two
1
QB10
Ice Blades, 10" Quantum, set of two
1
QT8N
Ice Auger, 8" Quantum
1
QT9N
Ice Auger, 9" Quantum
1
QT10N
Ice Auger, 10" Quantum
1
ACCESSORIES
EXT6
Depth Extension, 6"
EXT12
Depth Extension, 12"
EXT18
Depth Extension, 18"
