Figure 3: Terminal Positions EX-5120 Sensor/Transmitter

When wiring is complete, reassemble the

EX-5120

. Use caution when installing the overlay so as not to damage the magnetic

switches. Put the cover back on the S/T

Do Not apply power to the S/T without the cover in place.

Sensor/Transmitter
Enclosure Cutaway View

Printed Circuit Board

(PCB)

Display Overlay

Display Overlay Screws

(2 places)

Display Overlay Standoffs

(2 places)

Magnetic
Switches

(2 places)

Magnetic Switches

(2 places)

Printed Circuit Board (PCB)

J4 and J8 Terminals are located on the

bottom side of PCB

Display Overlay

Display

Optional
Relay Output Circuit Board

Display Overlay
