3.0 3.0 SPECTRUM-RAL Operation
Plug the power supply into an 110 V AC outlet. The display should read "0000" within ten seconds when the monitor is
supplied with uncontaminated air.
3.1 Operational Menu
The operational menu flow diagram is shown in Figure 3. This menu is accessed with the OPTION pushbutton
switch, the left hand switch as viewed from the front of the instrument. Successive displays are achieved by
repeatedly pushing the OPTION switch, as indicated by "O" in the menu flow diagram. The alarm acknowledgement
function, and displays and function in the "see DATA" area, are accessed with SELECT pushbutton, indicated by "S"
in the menu flow diagram.
Figure 3: Operation Menu Diagram
O
XX YY
°
C
No
Function
S
Maintenance
Menu Key
See Figure 4
Maintenance Section 4.0
O
Clr DATA Reset
Data S
O
go Setup
O
Min=XXXX No
Function S
O
O
S
Max=XXXX See DATA No
Function S
O
Alm=XXXX No
Function S
O
O
Batt=OK*
No
Function
*may also be
“low” or “LOW”
S
Operational
Display
XXXX Acknowledge
Alarm
S
S
O = O PTION Switch
S = S ELECT Switch
