EMP Tek EF30 - Manual (Page 7)

Model EF30 EF30C EF30T
Frequency Response: 60Hz – 20kHz ±3dB 60Hz – 20kHz ±3dB 45Hz – 20kHz ±3dB
Sensitivity: 86dB (2.83V@1m) 89dB (2.83V@1m) 87dB (2.83V@1m)
Recommended
Power:
50-100 Watts 60-120 Watts 70-150 Watts
Woofer(s): 5¼" (133mm)
Fiberglass
Dual 5¼" (133mm)
Fiberglass
8" (203mm) Pulp Cone
Subwoofer
Dual 5¼" (133mm)
Fiberglass
Tweeter: 1" (25mm) Poly Silk
Dome
1" (25mm) Poly Silk
Dome
1" (25mm) Poly Silk
Dome
Impedance: 8 Ohms 8 Ohms 8 Ohms
Crossover
Frequencies:
3000 Hz 3000 Hz 3000 Hz
Video Shielding: Yes Yes Yes
Dimensions: Width: 7¼" (184mm)
Height: 12¾" (324mm)
Depth: 8½" (216mm)
Width: 7¼" (184mm)
Height: 20¾" (527mm)
Depth: 8½" (216mm)
Width: 11" (279mm)
Height: 42½" (1080mm)
Depth: 13¾" (349mm)
Grille: Black Black Black
Finish: Black Black Black
Weight: 11 lbs. (4.99 kg) 17 lbs. (7.71 kg) 40 lbs. (18.14 kg)
Specifications
6
