Appendix A - Serial Remote Control (RS232)

XDS1 CD/SACD PLAYER OWNER’S MANUAL

Commands to the XDS1 (cont`d)

pol

Toggles polarity inversion performed in the digital domain.

src

Toggles between CD/SACD playback, AES and TOSLINK PCM inputs.

Status bytes sent from XDS1

The XDS1 sends back 9 Bytes terminated with a whenever any status changes.

Byte 0 Seconds ones in ASCII

Byte 1 Seconds tens in ASCII

Byte 2 Minutes ones in ASCII

Byte 3 Minutes tens in ASCII

Byte 4 Hours ones in ASCII

Byte 5 Track number ones in ASCII

Byte 6 Track number tens in ASCII

Command

Function

dim

Toggles through display brightness settings

try

Tray open and close

tr(x)

tr followed by a single digit (x) to jump to a particular track. See example.

tr(x) example:

a) Jump to track 5

tr0, tr5

b) Jump to track 12 :

tr1, tr2
