Rear Panel & Functions

Rear Panel & Functions

5. Analog Outputs:

• Left and Right Balanced (XLR) Connectors

• Left and Right Un-Balanced (RCA) Connectors

6. Digital Inputs:

• AES/EBU: AES/EBU (XLR) format PCM digital input

• TOSLINK: TOSLINK format PCM digital input

7. Digital Outputs:

• AES/EBU: AES/EBU (XLR) PCM digital audio output for Redbook CD

• EMM Labs OptiLink for interfacing with other EMM Labs products

8. System:

Remote:

•

Wired RS232: RS232 control port

Service:

•

USB data port for firmware upgrades (see separate USB update

instructions)

•

RESET button Used to temporarily access the backup firmware.

Only for diagnostic purposes. Should not be used during normal

operation.
