PARTS LIST
Fireplace
Models EFS33NR, VSGF33NR, EFS33PR & VSGF33PR
PARTS LIST
FIREPLACE
EFS33NR, VSGF33NR
EFS33PR, VSGF33PR
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 23 of this manual.
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
101357-01
Top Outer Casing
1
2
103207-01
Outer Casing
1
3
102758-02CK
Right Front Side
1
4
102759-02CK
Left Front Side
1
5
098304-01
Phillips Pan Head Screw, #10
17
6
101351-01CK
Top Front
1
7
102455-02
Top Louver Assembly
2
8
101353-01CK
Middle Front Rail
1
9
101712-02
Firebox Hood
1
10
101348-01
Firebox Support
2
11
099230-01
Shoulder Screw
4
12
101872-03
Firebox Top
1
13
101346-01
Outer Base
1
14
101838-03CJ
Firebox Wrapper
1
15
101514-01
Cover
1
16
M11084-26
Hex Screw, #10
57
17
098304-03
Phillips Pan Head Screw, #8
4
18
101727-03
Screen Assembly
1
PARTS AVAILABLE — NOT SHOWN
100639-01
Caution Decal
1
103590-01
Decal Strip
1
104313-01
Hinge, Pin
1
104313-02
Hinge, Pin
1
M10908-2
Screw, Slotted Hex Head Tapping
4
