Elenco Understanding Logic Gates - Manual (Page 3)

Outline
1. Digital Signals
2. NOT Gate (Inverter)
3. AND Gate
4. OR Gate
5. NAND Gate
6. NOR Gate
7. Exclusive OR Gate
Warning: Shock Hazard – Never connect Snap Circuits® to the electrical outlets in your home in any way!
Warning: Choking Hazard – Small parts. Not for children under 3 years.
Warning: Always check your wiring before turning on a circuit. Never leave a circuit unattended while the batteries are installed. Never connect
additional batteries or other power sources to your circuits. Discard any cracked or broken parts.
Batteries:
• Use only 1.5V AA type, alkaline batteries.
• Insert batteries with correct polarity.
• Do not mix old and new batteries.
• Remove batteries when they are used up.
• Do not short circuit the battery terminals.
• Non-rechargeable batteries should not be recharged.
Rechargeable batteries should only be charged under adult
supervision, and should not be recharged while in the product.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(nickel-cadmium) batteries.
• Do not connect batteries or battery holder in parallel.
• Never throw batteries in a fire or
attempt to open its outer casing.
• Batteries are harmful if swallowed,
so keep away from small children.
