How to connect your system
See illustration 1.
Outputs
Balanced analogue operation:
Use an XLR interconnect and connect the right and left outputs on the ECC-1 to the right
and left inputs on the integrated amplifier or preamplifier
Unbalanced analogue operation:
Use Phono interconnects and connect the right and left outputs on the ECC-1 to the right
and left inputs on the integrated amplifier or preamplifier
S/P DIF digital operation:
Use a 75-ohm coaxial digital cable from the ECC-1 to the digital input on your DAC.
Front panel
See illustration 2.
The main switch is located on the centre of the front panel.
The four buttons on the right-hand side of the front panel is used to play, stop, eject and
skip to previous/next track.
Function Button
Play Up button
Stop Down button
Eject Down button (hold button pressed until tray eject)
Previous track Left button
Next track Right button
Navigator window
The navigator window is located on the left side and shows what track is playing, time left
etc.
