EarthQuake WP6530 User Manual
Page 14
Operator's Manual
WP6520 and WP6530 Water Pumps
Check for parts online at
www.getearthquake.com or call 800-345-6007 M-F 8-5
14
kEy PART #
DESCRIPTION
QTy.
1
--
CASE OUTBOARD PUMP 2 INCH
1
2
--
CASE INBOARD PUMP 2 INCH
1
3
913302
FLANGE DISCHARGE PUMP 2 IN
1
4
913303
FLANGE INLET PUMP 2 IN
1
5
913305
IMPELLER PUMP 2 IN
1
6
913306
VOLUTE PUMP 2 INCH
1
7
92702
CAP PRIMER PUMP 2 IN
2
8
913350
FLAP CHECK PUMP 2 IN
1
9
913350
GASKET DISCHARGE PUMP 2 IN
1
10 913350
O-RING CASE PUMP 2 IN
1
11 913350
O-RING VOLUTE PUMP 2 IN
1
12 92702
GASKET PUMP PRIMER CAP
2
13 913350
WASHER M8 RUBBER
4
14 913346
KIT PUMP SEAL 2 IN
1
15
--
BOLT M8 X 20 HHCS GR 8.8 ZN F-T
11
16
--
BOLT M8 X 25 HHFCS GR8.8 ZN
4
17
--
BOLT M8 X 55 HHFCS GR8.8 ZN
4
18
--
BOLT M8 X 1.25 X 30 HHFCS GR8.8 ZN
4
19
--
WASHER FLAT M8 8.4 X 16 X 1.6 THK
GR8.8 ZN
11
20
--
WELDMENT FRAME PUMP 2 INCH
1
21 92701
BASE FOOT RUBBER WATER PUMP
4
22 --
NUT M8 X 1.25 HSF
8
23 92000
ENGINE 196CC
1
--
92772
REPLACEMENT PUMP (NOT
SHOWN)
1
--
92779
KIT ATTACHMENTS 2” PUMP (NOT
SHOWN)
1
WP6520 PARTS LIST
WP6530 PARTS LIST
kEy PART # DESCRIPTION
QTy.
1
92701
BASE FOOT RUBBER WATER PUMP
4
2
--
BOLT M8 X 25 HHFCS GR8.8 ZN
11
3
--
BOLT M8 X 20 HHCS GR 8.8 ZN F-T
4
4
--
BOLT M8 X 1.25 X 30 HHFCS GR8.8 ZN
4
5
--
BOLT M8 X 55 HHFCS GR8.8 ZN
4
6
--
NUT M8 X 1.25 HSF
8
7
913359
KIT PUMP SEAL 3 INCH
1
8
--
CASE INBOARD PUMP 3 INCH
1
9
913351
IMPELLER PUMP 3 INCH
1
10 913343
WASHER M8 RUBBER
4
11 913326
VOLUTE PUMP 3 INCH
1
12 913343
O RING PUMP VOLUTE 3 INCH
1
13
--
CASE PUMP OUTBOARD 3 INCH
1
14 913343
O RING PUMP CASE 3 INCH
1
15 913343
CHECK FLAP PUMP 3 INCH
1
16 913323
FLANGE INLET PUMP 3 INCH
1
17 92702
GASKET PUMP PRIMER CAP
2
18 92702
CAP PRIMER PUMP
2
19 913343
GASKET PUMP DISCHARGE 3 IN
1
20 913322
FLANGE DISCHARGE PUMP 3 IN
1
21 --
WASHER FLAT M8 8.4 X 16 X 1.6 THK
GR8.8 ZN
11
22 92000
ENGINE 196CC
1
23 --
WELDMENT FRAME PUMP 3 INCH
1
--
92773
REPLACEMENT PUMP (NOT
SHOWN)
1
--
92781
ATTACHMENT KIT 3” PUMP (NOT
SHOWN)
1
noTE: When no part number is listed above, the corresponding part is not serviced. If any of those parts should fail, use P/n 92772
(WP6520) or 92773 (WP6530) to order a replacement pump. hardware can be purchased at a local hardware store or repair center.
