Auger parts explosions, Ext12, Ext18 – EarthQuake 10310 User Manual
Page 17
Check for parts online at
www.getearthquake.com or call 800-345-6007 M-F 8-5 CST
17
Operator's Manual
Dually Earth Auger Powerhead
6
8, 9
23
5
10
18
19
14
23
15
11
21
3
22
7
1
4
18
19
5
2
20
16
19
5
4
12
21
3
22
7
1
18
2
20
BALLOON #
PART #
DESCRIPTION
QTY.
1
154
EARTH AUGER WELDMENT 10 IN RH
1
2
8980
SHOCK SPRING
1
3
EB10A
BLADE EARTH 10INCH CUT AND SHARPENED
1
4
EBOLT
BOLT 1/4-28 X 5/8 HH GR5 ZN
2
5
1423
BOLT 5/16-18 X 2 HH GR5 ZN
2
6
WF516
WASHER FLAT 5/16 INCH STANDARD ZN
2
7
60G56
NUT-LOC 5/16-18 BI-WAY ZN
2
8
ENUT
NUT-LOC 1/4-28 BI-WAY
2
9
8958HD
FISH TAIL POINT
1
10
1151
DECAL AND ART WARNING AUGER ICE AND EARTH
1
11
I10
INSERT 10 IN AUGER BOX
2
12
1433
BOLT 3/8-16 X 1-1/2 HH
1
13
2104
NUT 3/8-16 HLKBW ZN
1
14
LBB10P
ASSEMBLY BOX UPC STENCIL EA10F
1
7
5
17
19
13
21
2
1
4
20
18
Ea6F
Ea2F, Ea3F
Ea4F
Ea8F
Ea10F
aUGER PaRTS ExPlOSIONS
24
REVISIONS
ECN #
REV.
DESCRIPTION
DATE
BY
8682
1
CREATED PRINT
3/8/2011
MDO
BALLOON #
PART #
DESCRIPTION
ASSEMBLED/QTY.
1
553B
WELDMENT 12 INCH EXTENSION
1
2
1433
BOLT 3/8-16 X 1-1/2 HH
1
3
2104
NUT 3/8-16 HBW GR5 ZN
1
PARTS TO BE FREE OF
BURRS AND SHARP EDGES
THIS DRAWING AND ALL INFORMATION CONTAINED HEREIN IS AND REMAINS THE PROPERTY
OF ARDISAM INC.
AND IS CONFIDENTIAL. IT IS SUBMITTED AND MAY BE USED ONLY IN CONNECTION WITH
ARDISAMS' PROPOSALS
AND/OR ITS CUSTOMERS' ORDERS. IT SHALL NOT BE DISCLOSED TO OTHERS OR COPIED
WITHOUT ARDISAMS'
SPECIFIC WRITTEN CONSENT AND SHALL BE IMMEDIATELY RETURNED UPON REQUEST.
MATERIAL
NAME
TREATMENT
DR BY
APPD
PRT NO
EXT12
PT WEIGHT
SURFACE AREA
DATE
REVISION
THIRD ANGLE PROJECTION
SEE BILL OF MATERIALS
NONE
697.20
57969.61
12 INCH EXTENSION
1
MOlsen
MDO 1/19/2011
03/08/2011
SHEET: 1 OF 2
ALL ANGLES ARE DECIMAL DEGREES
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS
THREADS CLASS 2
0.0 ± 1.0°
0 ± 2°
ANGLES:
0.000 ± 0.250 MM
0.00 ± 0.75 MM
0.0 ± 2.5 MM
OTHERWISE NOTED:
TOLERANCE UNLESS
ExT12
25
REVISIONS
ECN #
REV.
DESCRIPTION
DATE
BY
8682
1
ISSUED DRAWING
3/8/2011
MDO
BALLOON #
PART #
DESCRIPTION
ASSEMBLED/QTY.
1
553C
WELDMENT 18 INCH EXTENSION
1
2
1433
BOLT 3/8-16 X 1-1/2 HH
1
3
2104
NUT 3/8-16 HBW GR5 ZN
1
PARTS TO BE FREE OF
BURRS AND SHARP EDGES
THIS DRAWING AND ALL INFORMATION CONTAINED HEREIN IS AND REMAINS THE PROPERTY
OF ARDISAM INC.
AND IS CONFIDENTIAL. IT IS SUBMITTED AND MAY BE USED ONLY IN CONNECTION WITH
ARDISAMS' PROPOSALS
AND/OR ITS CUSTOMERS' ORDERS. IT SHALL NOT BE DISCLOSED TO OTHERS OR COPIED
WITHOUT ARDISAMS'
SPECIFIC WRITTEN CONSENT AND SHALL BE IMMEDIATELY RETURNED UPON REQUEST.
MATERIAL
NAME
TREATMENT
DR BY
APPD
PRT NO
EXT18
PT WEIGHT
SURFACE AREA
DATE
REVISION
THIRD ANGLE PROJECTION
SEE BILL OF MATERIALS
NONE
1049.56 81683.44
18 INCH EXTENSION
1
MOlsen
MDO 1/20/2011
03/30/2011
SHEET: 1 OF 2
ALL ANGLES ARE DECIMAL DEGREES
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS
THREADS CLASS 2
0.0 ± 1.0°
0 ± 2°
ANGLES:
0.000 ± 0.250 MM
0.00 ± 0.75 MM
0.0 ± 2.5 MM
OTHERWISE NOTED:
TOLERANCE UNLESS
ExT18
