EarthQuake E43 User Manual
Page 17
ASSEMBLY INSTRUCTIONS ANd PARTS ExPLOSIONS
E43 Model
Page 17
GetEarthquake.com
800-345-6007
E43 ENGINE PARTS LIST
kEY
NO.
PART NO. dESCRIPTION
qTY.
1
300484
FLYWHEEL, MAGNETO
1
2
300337
NUT, FLANGE M8
1
3
300462
WASHER, ROTOR
2
4
300413
CLUTCH ROTOR ASSEMBLY
1
5
300412
SPRING, CLUTCH
1
6
300449
WASHER, SPRING
2
7
300450
BOLT, SHOULDER
2
8
300467
PIN, LOCATING
2
9
3004110
MOUNT RING & SHROUD
1
10
300491
RECOIL CLUTCH
1
11
300429
PLATE, RECOIL
1
12
3004121
HANDLE, RECOIL (STANDARD)
1
13
300430
RECOIL ASSEMBLY WITH
STANDARD HANDLE
1
14
300472
IGNITION COIL
1
--
300472CE IGNITION COIL CE
1
15
300482
SHROUD, ENGINE
1
16
300493
BOLT, STUD M6 X 62MM
2
17
300475
GASKET, MUFFLER
1
18
4813
MUFFLER
1
19
4812
COVER, MUFFLER
1
20
BM6A
SPARK PLUG
1
21
300483
COVER, ENGINE SHROUD
1
22
300476
GASKET, INTAKE
1
23
300478
WINDPIPE, INTAKE 43CC/51CC
1
24
300479
GASKET, CARBURETOR
1
25
300486
CARBURETOR
1
26
300481
O-RING, CARBURETOR
1
27
3004109
PRIMER BULB
1
28
300329*
BASE, INTAKE
1
29
300340*
CHOKE LEVER, SIDE MOUNT
1
30
300328*
CHOKE COVER
1
31
3004132* SCREW, THROTTLE LEVER
1
32
300455
PLATE, INTAKE COVER
ADAPTER
1
33
300457
COVER, AIR FILTER
1
34
300435
AIR FILTER
1
35
300330
COVER, INTAKE
1
kEY
NO. PART NO. dESCRIPTION
qTY.
36
56105
BRACKET, GAS TANK
1
37
300331
GAS TANK
1
38
300401
GAS CAP, MANUAL VENTING
1
39
300332
SHROUD, GAS TANK
1
40
1021
SWITCH, ROCKER
1
41
300494
GROMMET, 2-HOLE GAS TANK
1
42
300497
HOSE, PRIMER LINE
1
43
300498
HOSE, FUEL LINE
1
44
300335
BOLT W/WASHER PHILLIPS HH
4
45
300492
NUT, FLANGE M6
2
46
300471
BOLT W/WASHER M5 X 12MM
5
47
300439
BOLT W/WASHER PH M5 X 18MM
7
48
300336
BOLT HH M6 X 10MM
2
49
300438
BOLT W/WASHER M5 X 25MM
2
50
300456
BOLT M5 X 50MM
2
51
300326
GUARD, SCREW
1
52
300338
KEY, FLYWHEEL
1
53
3004103
FILTER, FUEL
1
54
300351
BOLT HH M6 X 8MM
2
55
3004158
COVER, AIR FILTER
1
56
30041501* BASE, AIR FILTER
1
57
3004156
FOAM, AIR FILTER
1
58
3004157
PLATE, REINFORCEMENT
1
59
3004153* BOLT, CHOKE LEVER
1
60
3004155* WASHER, CHOKE LEVER
2
61
3004154* NUT, NYLOC, CHOKE LEVER
1
62
3004151* CHOKE LEVER
1
63
3004152* CHOKE PADDLE
1
-
300470
FUEL LINE HOSE & FILTER
1
-
3004114 KIT, CARBURETOR
1
* P/N 3004150 Air Filter Base sold as an assembly unit only.
*For reference only. Contact customer service for replacement.
