EarthQuake E43 User Manual
Page 15
ASSEMBLY INSTRUCTIONS ANd PARTS ExPLOSIONS
E43 Model
Page 15
GetEarthquake.com
800-345-6007
E43 POWERhEAd PARTS LIST
kEY
NO.
PART
NO.
dESCRIPTION
qTY.
1
E43CC2
GAS ENGINE, 43CC
1
2
1027F
HANDLEBAR, FOAMED
1
3
3004119 TRANSMISSION COMPLETE
1
4
4809
TRIGGER ASSEMBLY
1
5
4814
BOLT 10-24 X 1-1/4 PHILLIPS
TRUSS HD
1
6
4811
THROTTLE CABLE
1
7
8930B
BOLT 1/4-20 X 3/4 HH GR5 BLK
4
8
3004111 GEAR CASE TOP
1
9
3004100 CLUTCH DRUM
1
10
8922
BALL BEARING R12 DOUBLE LIP
3
11
9814
GEAR 7T PINION THREADED,
5/8” THREAD
1
12
8924
SNAP RING
2
13
8915
DOWEL PIN STEEL 1/4” X 1/2”
1
14
8912
GEAR 44T 3/4” HOLE
1
15
8919
GASKET
1
16
8923
BALL BEARING R10
2
17
9214
GEAR 10T/48T ONE-PIECE
CLUSTER
1
18
8939
GEAR CASE BOTTOM
1
19
8913
SHAFT OUTPUT 7/8”
1
20
8929
BOLT 1/4-20 X 1-1/2 SHCS
2
21
8931F
BOLT 1/4-20 X 2 SHCS F-T
4
ALTERNATE ASSEMBLY
9
3004104 CLUTCH DRUM
1
11
9814MM GEAR 7T PINION THREADED,
8MM THREAD
1
35
300409
SPACER
1
kEY
NO.
PART
NO.
dESCRIPTION
qTY.
22*
EA2F
EARTH AUGER 2”, COMPLETE
1
EA3F
EARTH AUGER 3”, COMPLETE
1
EA4F
EARTH AUGER 4”, COMPLETE
1
EA6F
EARTH AUGER 6”, COMPLETE
1
EA8F
EARTH AUGER 8”, COMPLETE
1
EA10F
EARTH AUGER 10”, COMPLETE
1
23
1423
BOLT 5/16-18 X 2 HHCS GR5
2
24
WF516
WASHER, FLAT 5/16” STANDARD
2
25
60G56
NUT 5/16-18 BI-WAY LOCK
2
26
53684
SHOCK TOP 1-PC
1
27
8980
SHOCK SPRING
1
28** EB4
EARTH BLADE, 4”
1
EB6
EARTH BLADE, 6”
1
EB8
EARTH BLADE, 8”
1
EB10
EARTH BLADE, 10”
1
EB6HD
HEAVY DUTY EARTH BLADE, 6”
1
EB8HD
HEAVY DUTY EARTH BLADE, 8”
1
EB10HD HEAVY DUTY EARTH BLADE, 10”
1
29
EBOLT
BOLT 1/4-28 X 5/8 HH GR5
2
30
ENUT
NUT 1/4-28 BI-WAY LOCK
2
31
8958HD
FISHTAIL POINT SHARPENED
1
8970
POINT, EARTH 2” & 3” AUGERS
1
32
1433
BOLT 3/8-16 X 1-1/2 HH
1
33
2104
NUT 3/8-16 HEX LOCK BI-WAY
1
34
143
SHOCK MECHANISM COMPLETE
(For reference only. Contact
customer service for replacement)
1
-
EXT6
DEPTH EXTENSION 6”
1
EXT12
DEPTH EXTENSION 12”
1
EXT18
DEPTH EXTENSION 18”
1
* Includes blade, fishtail point, shock spring, shock top, & hardware.
** Includes mounting hardware.
AUGER PARTS & ACCESSORIES LIST
