830R/T Operator’s Manual
830R Receiver
CMW
Display - Active (Left/Right) Mode
1.
Signal strength
2.
Left/Right indicator
3.
Battery level
4.
Frequency indicator
5.
Volume level
6.
Gain indicator
7.
Signal strength indicator
Item
Description
Notes
1.
Signal Strength
Numerically displays the
signal strength.
2.
Left/Right Arrow
Indicates the direction and
relative distance to the line.
999
e16om001t.eps
1
2
3
4
5
6
7
