plug the adapter into an outlet. DO
NOT SUBSTITUTE AC ADAPTERS.
Only use the AC adapter provided with
the scale. NOTE: Use of an AC adapter
other than the one provided may dam-
age the scale.

C. About the Scale:

1. Select a FLAT and LEVEL surface

which is not subject to

vibration or air

movement

2. A transparent, protective plastic

coating has been added over the LCD
display to prevent scratches during
shipment. This should be removed
before operation to provide a clear
view of the display. FIG 5.

3. Turn the scale on by pressing the

button marked

“ON/OFF” once FIG 6.

The scale is now on. The display will
show “+88.8.8.8.” and then “0.00” with
a small arrow pointing to “g:gram” on
the extreme right side of the display.
This indicates that the scale is ready to
use. The “CAL/MODE” key will allow
you to toggle between GRAMS and
GRAINS after turning the scale on,
even if there is something being
weighed at the time.

4. When this scale is used in any

location where air movement may be a
factor, the “draft shield” should be used
to cover the weighing platform. FIG 7.

This prevents inaccurate readings due
to environmental influences.

This specially designed cover incor-

porates a grounding feature which
removes any static electricity within the

Fig. 4

Fig. 7

Fig. 5

Fig. 6
