Deltech Fitness DF4500L- Pro Power Rack with Lat Attachment User Manual
Page 10
INSTALL THE CHIN-UP BAR ASSEMBLY (G), BETWEEN THE TOP FRAME SUP-
PORTS USING THE M12 x 75MM BOLTS (P), M12 WASHERS (Q), MOUNTING
FLANGES (S), AND M12 NUTS (R).
INSTALL THE UPPER CROSSMEMBER (F), BETWEEN THE REAR UPRIGHTS USING
THE M12 x 75MM BOLTS (P), M12 WASHERS (Q), AND M12 NUTS (R).
R
R
R
R
Q
Q
Q
Q
Q
R
Q
S
S
P
P
P
P
G
Q
F
FRAME ASSEMBLY
