Deltech Fitness DF4500- Pro Power Rack User Manual
Page 10
INSTALL THE CHIN-UP BAR ASSEMBLY (G), BETWEEN THE TOP FRAME SUPPORTS
USING THE M12 x 75MM BOLTS (P), M12 WASHERS (Q), MOUNTING FLANGES (U),
AND M12 NUTS (S).
INSTALL THE UPPER CROSSMEMBER (F), BETWEEN THE REAR UPRIGHTS USING
THE M12 x 75MM BOLTS (P), M12 WASHERS (Q), AND M12 NUTS (S).
R
S
S
S
Q
Q
Q
Q
Q
Q
Q
U
U
P
P
P
P
G
Q
F
FRAME ASSEMBLY
