SPACE- -TIME TOOL MASTER KIT I STRUCTIO S
PART # D7020MK
CO GRATULATIO S!
You have just purchased the most innovative and practical
tool available for 1970 to 1999 “Big Twin” single cam HARLEY-DAVIDSO * style
engines. This DELKRO tool is all you will need to professionally setup everything in
the cam chest of your engine. By simply following these step by step instructions, you
can build a more durable and powerful engine in a lot less time than other methods by
eliminating the “Guess Work” and building an engine with true confidence and peace of
mind.
CAMSHAFT E D-PLAY
The recommended camshaft end-play for a high performance application is .005” to
.015” with .010” being the nominal target. The following method will allow you to check
your camshaft end-play.
DIAL I DICATOR METHOD
– With your camshaft installed, using O LY the
thrust washer, install your DELKRO Space-N-Time tool, along with your cam cover
gasket in place of your cam cover and torque the tool to the crankcase (use OEM torque
spec.)
Mount the dial indicator to the outer face of the tool so that the indicator shaft is in line
and contacting the camshaft end protruding through the tool. Push the camshaft back
