• Simultaneous output possible for all video signals
• Supports PAL and NTSC
• THX Ultra certified
■ Audio Section
• Advanced AL24 Processing, original DENON technology for high-quality audio
The DVD-5910CI employs Advanced AL24 Processing, the ultimate analog wave-
form reproduction technology developed by Denon, for use during PCM signal
input (during stereo signal processing). In addition to the data expansion of exist-
ing AL24 Processing Plus technology, algorithms developed by Denon for use in
large-capacity calculation processors such as DSPs and FPGAs are used to
interpolate data along the time axis and up-converted sampling is used to achieve
natural interpolation without losing original data. Greater optimization in digital fil-
tering has also been achieved for ringing-free pulse response and for pulsive
music data and attack sounds. This results in more natural reproduction of spa-
tial information such as the delicate nuances in the music, the locations of the
performers, and the breadth, height and depth of the concert hall.
For multi-channel linear PCM audio playback, AL24 Processing Plus technology
works to faithfully reproduce the original sound of recordings.
• High-accuracy D/A converters for all channels
Two of the latest high-accuracy 24-bit, 192-kHz differential operation D/A con-
verters have been dedicated to the two stereo channels, and three additional
DACs are used for 5.1-channel playback, delivering significantly improved separa-
tion and superior S/N, dynamic range and other aspects of audio performance.
Since highly accurate D/A conversion is achieved for all channels, the sonic result
is refreshingly transparent. During 2-channel stereo playback, these D/A convert-
ers are used in monaural mode, operating as differential output converters inde-
pendently dedicated to the left and right channels, to achieve high-quality play-
back of stereo signals.
• Audio output dedicated to high-quality 2-channel playback
• Pure Direct mode, for greater purity in the audio signal
• DENON Link 3rd, for high-grade audio transmission
• IEEE 1394 digital interface
• HDMI output, for multi-channel audio
• Designed for high sound quality
• Bass management function tailored for home theater environments
■ Construction
• Construction designed to thoroughly suppress vibration and mutual
interference among circuit blocks
- Four-box layout to isolate circuits and minimize mutual interference
- Thorough vibration-resistant construction
• DENON original high-accuracy drive mechanism
■ Other Features
• Supports playback of a wide variety of discs
• Playback frequency ranges of Super Audio CDs are switchable
(50 kHz / 100 kHz)
• Independent bass management for analog audio output and HDMI audio signals
• Remote controller with backlight keys
• Wealth of output terminals
Output Terminals For Every A/V System
Video outputs
HDMI: 1
DVI-D: 1
Component: 2 sets (RCA, BNC)
Composite: 2
S-Video: 2
Audio outputs
Optical digital: 1
Coaxial digital: 1
DENON Link: 1
IEEE 1394: 2
Analog (L/R): 1 set
5.1-channel (FL/FR/C/SL/SR/SW): 1 set
Specifications
Video Section
Signal system
NTSC
Disc played
DVD Audio/Video, Music CD, SuperAudioCD, CD-R/RW(audio/MP3/WMA/JPEG),
Video CD, DVD-R/RW(Video mode), DVD+R/RWPicture CD
Video outputs
Composite Video Output
1.0 Vp-p (with 75 ohms load)
S-Video Output
Y; 1.0 Vp-p (with 75 ohms load),
C; 0.286 Vp-p
Component Video Output Y, Pb/Cb, Pr/Cr:
Y; 1.0 Vp-p (with 75 ohms load),
Pb/Cb; 0.648 Vp-p (with 75 ohms load),
Pr/Cr; 0.648 Vp-p (with 75 ohms load)
Audio Section
Frequency response
DVD
2 Hz - 88 kHz (192 kHz sampling),
2 Hz - 44 kHz (96 kHz sampling),
2 Hz - 22 kHz (48 kHz sampling)
Super Audio CD
2 Hz - 100 kHz
CD, VCD
2 Hz - 20 kHz
Signal-to-noise ratio
125 dB
Dynamic range
112 dB
Total harmonic distortion
0.0008%
General
Power supply
AC 120 V, 60 Hz
Power Consumption
80 W
Dimensions
17-3/32” x 6-11/16” x 17-1/64”
434 (W) x 170 (H) x 432 (D) mm
Weight
41 lbs 14 oz, 19.0 kg
