Da-Lite Tensioned Conference Electrol - Manual (Page 6)

6
Blue (Common)
Brown (Hot)
Green/Yellow
(Ground)
Blue (Common)
Brown (Hot)
Blue (Common)
Brown (Down)
Black (Up)
Green/Yellow
(Ground)
QEYE
QAUX
QEYE
QEYE
NOTE: 20-24AWG wire recommended for dry contact wiring.
220V Wiring Diagram
SCREEN
AND
CAMERA
SCREEN
CAMERA
STOP
Front of Wall Keypad Back of Wall Keypad
Camera
Arm Motor
Black (Up)
Brown (Down)
Blue (Common)
Green/Yellow (Ground)
Black (Up)
Brown (Down)
Blue (Common)
Screen Motor
Screen Controller
Board
Camera Arm
Controller Board
Splitter
Door Motor
NOTE:
Ground Must
Be Connected
to Building
Ground
Dry Contacts
for Screen
Power Input
220VAC/50Hz
White (Common)
Red (Up)
Black (Down)
Black (Down)
White (Common)
Red (Up)
Green/Yellow (Ground)
Green
RJ-25 Pin-Outs (Tab Is Facing Up)
Standard RJ-25 can be used in place of RJ-14 cable
Bus (RP Data)
+12V
RQ Clock
RQ Data
+5V
Ground
Yellow
Red
Black
White
Blue
RJ-45 Pin-Outs (Tab Is Facing Up)
+12V
Manual 2
Ground
Manual 1
RQ Clock
Bus (RP Data)
RQ Data
+5V
Blue
Green
Yellow
Red
Black
Orange
Purple
Brown
RJ-14 Pin-Outs (Tab Is Facing Up)
Supplied RJ-14 cable
Bus (RP Data)
RQ Data
+5V
Ground
White
Green
Red
Black
RJ-14 cable
(supplied)
RJ-14 cable
(pre-installed)
RJ-14 cable
(pre-installed)
Dry Contacts
for Camera
Arm
