19 GLOW UP
EDIT SCENE
To create/overwrite/modify a SCENE customised by the user:
1) Press ENTER A – SCENE 1 appears on the display.
2) Use the UP B and DOWN C keys to select from the ten available
SCENES.
3) Press ENTER A to open a SCENE.
4) A value can be associated with each GlowUp channel inside each
SCENE using the UP B and DOWN C keys.
5) When finished with settings, press SELECT S . A confirmation
message appears: SAVE SCENE X ?.
6) Press ENTER A to confirm and save the SCENE or SELECT S to
return to the previous menu.
EDIT SEQUENCE
Allows you to create a sequence, made up of a series of SCENES saved
by the user.
1) Press ENTER A – MEMORY 1 appears on the display.
2) Use the UP B and DOWN C keys to select one of the ten
MEMORIES available.
3) Press ENTER A to access the MEMORY
4) Press ENTER A to access the MEMORY and add/delete/modify
STEPS with SCENE/SPEED/FADE as required.
5) Press ENTER A to confirm the selection or SELECT S to return to
the previous Menu.
DMX RECORDER
To record a scene sequence programmed on the unit.
The projector must be set to Slave --> Receiver in order to accept a
recording. Press ENTER A and reset the "Memory" by pressing
ENTER A again. GlowUp is now ready to store control unit DMX data
(DMX waiting ...).
On completing the recording, press ENTER A to save, otherwise
press SELECT S Esc.
DMX ADDRESS
Allows the user to set the DMX address to be assigned to the projector.
1) Press ENTER A – the current DMX address appears on the display.
2) Use the UP B and DOWN C keys to set the DMX address.
3) Press ENTER A to confirm the selection (the display blinks for
several seconds) or SELECT S to keep the current settings and
return to the previous Menu.
To enable the "Advanced Menu" set up the "Access code" (1234) using the
UP B , DOWN C , RIGHT E keys.
Press F - "Menu advanced" appears on the display
RADIO
Assigns the desired command to the GlowUP Radio module Radio.
1)Press ENTER A – current settings appear on the display.
2)Use the UP B and DOWN C keys to select one of the following settings:
Unlink Trasmitter – Disconnected from the transmitter
Link Receivers – Connected to all free receivers
Unlink Receiver – Disconnected from all receivers
Tx mode – allows the user to select either the G3 (recommended for those
who don't use RDM-wireless controls) or G4 (recommended only if RDM-
wireless controls are used) transmission channels. Press ENTER A and
use the UP B and DOWN C keys to select one of the two available
channels.
RDM discovery – to be used only when the wireless card is replaced;
press ENTER A to start the automatic search option.
3)Press ENTER A to confirm the selection (the display blinks for
several seconds) or SELECT S to keep the current settings and
return to the previous Menu.
PROGRAM MENU
DMX ADDRESS MENU
ADVANCED MENU
Continued ➔
Program Edit scene
Edit
Sequence
DMX
recorder
Add step
Delete step
Modify step
Scene
Speed
Fade
DMX
Address
Memory 1
...
...
Memory 10
Setup Radio
Code
1234
Advanced
