English – Clay Paky TIGER SCAN User Manual
Page 3
9
CHANNEL FUNCTIONS
5
CANNEL
FUNCTION
1
GOBO ROTATION
2
COLOUR WHEEL
3
GOBO SELECTION
4
DIMMER/STOPPER/STROBE
5
PAN
6
TILT
2
0
1
3
4
5
6
8
9
10
7
• TILT - channel 6
0
1
2
3
4
5
6
7
8
9
10
White
1
2
3
4
• GOBO SELECTION - channel 3
0
1
2
3
4
5
6
7
8
9
10
100%
75%
50%
0%
STOP
540
°
360
°
0
°
From 0% to 49.7% the gobo rotates
through 540° (1
1/2
turns).
From 50% to 75% the gobo rotates
more quickly at first and then slows
down to a complete stop.
From 75.5% to 100% the gobo begins
turning in the opposite direction, slow-
ly at first and then gradually faster.
The change occurs instantaneously as
the slider reaches different preset lev-
els on the graduated scale.
Vertical movement (Tilt) of the mirror
occurs gradually as the slider is
advanced. From the zero position mir-
ror movement is linear and continuous
up to the opposite end of travel. The
mirror can be stopped at any interme-
diate angle.
• GOBO ROTATION - channel 1
• COLOUR WHEEL - channel 2
0
1
2
3
4
5
6
7
8
9
10
PINK
BLUE
ORANGE
GREEN
VIOLET
YELLOW
RED
WHITE
In the 0% to 50% range of adjustment
the colour change in response to
movement of the potentiometer is lin-
ear and continuous so that the slider
can be stopped in intermediate posi-
tions to obtain a two-colour beam.
From 50% to 100% the wheel rotates
continuously with speed increasing
steadily from 0 to 300 rpm.
0
1
3
5
6
7
8
9
10
4
2
• DIMMER/STOPPER/STROBE - channel 4
In the 0% to 50% range of adjustment,
the dimmer opens gradually to maxi-
mum aperture.
Strobe effect is produced from 54.7%
to 95%, with frequency increasing
from 1 to 7 flashes/second.
The aperture remains fixed between
95% and 100% of the range.
6
8
10
0
1
2
3
4
5
7
9
Horizontal movement (Pan) of the mir-
ror occurs gradually as the slider is
advanced. From the zero position mir-
ror movement is linear and continuous
up to the opposite end of travel. The
mirror can be stopped at any interme-
diate angle.
• PAN - channel 5
ENGLISH
