42 SUPERSHARPY
Channel Mode DMX
Value
Function
Standard Vector
FROST
0 - 255
Frost moves linearly into the light beam
Frost blades move from no-diffusion to maximum diffusion in 0.02 seconds at
maximum speed.
FOCUS
0 - 255
Focus moves linearly from far to near position.
Focus lenses move from farest to nearest position in 1.11 seconds at
maximum speed.
PAN
0 - 255
Pan movement/positioning from 0° to 540°
•
Fast Speed: 3.301 sec
•
Normal Speed: 4.038 sec
FINE PAN
0 - 255 Fine Pan positioning
TILT
0 - 255
Tilt movement/positioning from 0° to 244°
•
Fast Speed: 2.060 sec
•
Normal Speed: 2.274 sec
FINE TILT
0 - 255 Fine Tilt positioning
FUNCTION
0 - 11 Unused range
12 - 24 Fast Pan / Tilt speed (default)
25 - 37 Normal Pan / Tilt speed
63 - 75 CMY Full Range (default)
76 - 87 CMY Limited range
88 - 101 CMY shortcut ON (default)
102 - 114 CMY shortcut OFF
115 - 255 Unused range
The functions are activated/selected passing through the unused levels range
and staying in the necessary range for 5 seconds.
RESET
0 - 25 Unused range
26 - 76
Zoom Reset
Zoom Reset sequence is activated passing through the unused levels range
and staying in this range for 5 seconds
77 - 127
Pan / Tilt Reset
Pan/Tilt Reset sequence passing through the unused levels range and staying
in this range for 5 seconds.
128 - 255
Complete Reset
All-effects Reset sequence passing through the unused levels range and
staying in this range for 5 seconds.
LAMP CONTROL
0 - 25 Unused range
26 - 100
Lamp OFF
Lamp switch-off passing through the unused levels range and staying in this
range for 5 seconds.
101 - 255
Lamp ON
Lamp switch-on passing through the unused levels range and staying in this
range for 5 seconds.
