ALPHA SPOT EASY 1200
1
Upper Side
2
16
ALPHA SPO
T EASY
1200
1
Lower Side
2
17
Continua / Continue
➔
35
Apertura e chiusura piastra supporto ventola (Upper side) - Figura 16
Apertura e chiusura piastra supporto ventola (Lower side) - Figura 17
Fan support plate opening and closing (Upper side) - Fig. 16
Fan support plate opening and closing (Lower side) - Fig. 17
Ouverture et fermeture de la plaque de support du ventilateur (Upper side) - Figure 16
Ouverture et fermeture de la plaque de support du ventilateur (Lower side) - Figure 17
Öffnung und Schließung Halteplatte des Lüfters (Upper side) - Abb. 16
Öffnung und Schließung Halteplatte des Lüfters (Lower side) - Abb. 17
Apertura y cierre placa de soporte ventilador (Upper side) - Figura 16
Apertura y cierre placa de soporte ventilador (Lower side) - Figura 17
