Sponge Bob SERVICE Menu Items

Service

Menu

Item

Configuration/

Test Name

Factory Default

Value

Menu Item Values & Description

Pay Mode

0 – Pay-for-Play 0 – Pay-for-Play

1 - Free-Play (Show/Demo) with NO Tickets Dispensed

Coins-per-Credit 1 Coin / Credit

1 – 9 coins per Credit

03 Prize

Dial

Setting

2 – Medium

1 – Prize Dial #1 - High
2 – Prize Dial #2 - Medium
3 – Prize Dial #3 - Low

Attract Mode

2 – Sounds, Lights
& Motion

0 – No attract mode
1 – No Sound
2 – Sounds, Lights & Motion

Skill Level

6 - l

1 – Easy
2 –
3
4 –
5 - Normal
6
7 - Hard
8 -
9 – Extremely Hard

Bill Acceptor

0 – none installed 0 – no Bill Acceptor Installed

1 – 9 Coins counted for each dollar
(assumes 1- active LOW pulse per dollar)

Clear Credits

n/a

Clears accumulated credits

Switch Test

n/a

Shows switch number of any switch (including INDEX and SECTOR
Optos) that is found to be “ON”. Values range from 00 – 31. A list of
switch numbers can be found in Section 6.

Lights Test

n/a

Use UP and DOWN switches to turn the various non-prize dial lights
ON and OFF. See Test 42 below for Prize Dial Lamps Test.

42 Prize

Dial

Lamps Test

n/a

Use UP and DOWN switches to sequentially turn Prize Dial Lamps
ON. UP turns Lamps on in a Clockwise direction, DOWN in a
Counter-Clockwise direction. The LED display shows the Sector
Number of the Lamp currently ON. Sector Numbers start at 12
o’clock == Sector 1.

Display Test

n/a

Use UP and DOWN switches to turn display ON and OFF. When ON,
the display shows ‘all eights’ 888

Motor Test

n/a

Use UP and DOWN switches to turn motor ON and OFF.

Sound Test

n/a

Use UP switch to exercise Sound Channel 1. Use DOWN switch to
exercise Sound Channel 2

46 Ticket

Dispenser

Test

n/a

Depressing the DOWN switch will dispense 1 ticket. UP dispenses 5
tickets. The Ticket Meter is not advanced during this test.

98 Restore

Factory

Defaults

0 – keep current
values

0 – keep current values
1 – Factory Default Configuration
