ZTR 560 PARTS LIST
1384
Tank Mount Bracket (Short)
3093
5/16"-18 UNC X 1" HH Bolt GR5
1385
Tank Mount Bracket (Long)
3105
1/4" x 1 1/4" Spirol Pin
1657
Spring - Belt Idler
3130
1/2" Contact Belleville Spring
1682
L-Rod
3140
1/4" ID Disc Spring
1701
Wheel/Deck Hub Bearing
3160
5/16" Flat Washer
1714
T-Box Drive Belt
3161
5/16"-24UNFLH Thread
1715
Rear Wheel & Tire
3163
1/2" Int Tooth Lock Washer
1732
Pulley - T-Box
3169
3/8"-16X1"HHBoltGR5
1733
Pulley - T-Box Drive
3178
3/8"-16X2 1/2" HH Bolt GR5
1734
Pulley - Hydrostat
3182
Flip Lock Bushing
1739
Hydrostat Idler Bracket
3186
#12-14 X 1" Drill & Tap Screw
1743
Hydrostat Flat Idler Pulley HD
3187
#10-32 Hex Nut
1745
Pulley
3188
#10 Ext Tooth Lock Washer
1752
Plastic Idler 4" Flat
3195
Face Nut 1/2"-27
1763
Tie Down x/lnsulator
3196
Face Nut 7/1 6"-28
1765
V-Belt
3201
Washer .533 ID X1. 37 OD
1834
Seat Strap
3203
3/8" ID Flat Washer (Narrow)
1849
Seat Spacer
3204
1/4"-20 Hex Nut x/Nylok
1895
Clutch Anchor
3205
5/16"-18HexNutw/Nylok
1911
Roller Bracket Weldment
3206
3/8"-16HexNutw/Nylok
1917
Rear Roller Bracket Weldment
3207
1/2"-13HexNutw/Nylok
2128
Sleeve
3208
#10-24 Hex Nut w/Nylok
2928
3/1 6" X1" Key
3224
5/16"-18 X 1" HH Bolt w/Nylok GR5
3002
5/16"-18X21/2"HHBGR8
3225
3/8"-16X21/4"HHBolt
3005
5/16"-18UNCHexNut
3227
5/16"-18X2"HHBoltGR5
3006
5/16"-18X 1/4" HH Bolt GR5
3231
9/1 6" Std Flat Washer
3007
1/4"-20 UNC Hex Nut
3235
#10-24 X 5/8" Phillips Pan HD Screw
3008
1/4" ID X 3/4" OD Flat Washer
3237
Eye Bolt 5/1 6" X 6.00"
3009
5/16"-18 UNC X 1 3/4" HH Bolt GR8
3243
5/16"-18X31/4"HHBoltGR5
3012
3/8"-16UNCHexNut
3245
3/8"-16 Thin Profile Nylok Nut
3014
1/4"-20 UNC X 3/4" HH Bolt GR5
3247
#6-20 X 1/2" Phillips Pan Hd Screw
3020
5/1 6" Std Flat Washer
3248
5/1 6" ID X 1/8" Thick Washer
3023
1/4" Helical Lock Washer
3249
5/8" Int Tooth Lock Washer
3033
1/2" SAE Flat Washer
3256
Snap Ring
3048
3/8"-16UNCX1 1/2" HH Bolt
3257
7/16" Int Tooth Lock Washer
3052
3/32" X1" Cotter Pin
3260
1/4"-20X1/2"HHBoltGR5
3057
3/8" Std Flat Washer
3264
5/16" Disc Spring HD
3061
5/16"-18 UNC 1 3/4" Soc Set Screw
3265
#10-24 X 3/4" Truss Hd Phillips Screw
3066
3/1 6" Std Flat Washer
3266
1/4" Int Tooth Lock Washer
3068
1/8"X1" Cotter Pin
3267
5/16"-18X1 3/8" HH Bolt GR5
3072
1/8" X 1 3/4" Hair Pin Cotter
3268
3/8"-24 X 1 1/4" HHB GR8 w/Nylok
3074
5/16"-24UNFHexJamNut
3269
5/1 6"-18X1" Soc Hd Bolt
3087
5/1 6"- 18 UNC X 3/4" HH Bolt GR5
3272
5/16" Int Tooth Lock Washer
3088
1/4"-20X1"HHBoltGR5
3273
8-1 8 X 3/8" Phillips Pan HD
