2.5 ESD/EMI solutions
Notification:
There are some ESD/EMI solutions that users have to consider before designing your own
Thermal solutions or Carrier board
Thermal solution:
Except CPU and Chipset contact area (Red Square), keep blue shade surface 5.45mm
away from surface of ESM-QM87.
Please refer to the pictures shown as below
5.45mm
Heat Sink
CPU
Chipset
ESM-QM87
