Page 12: 3 setting jumpers & connectors

background image

EEV-Q701

12 EEV-Q701 Quick Installation Guide

2.3 Setting Jumpers & Connectors

2.3.1

Touch selector (JTOUCH1)

*Default

5W*

4/ 8W

Signal

PIN

Y-

1

SENSE

2

NC

3

2.3.2

Brightness adjuster (JVR1)

*Default

GND*

Signal

PIN

PIN

Signal

+5V

1

2

BK_DC_ADJ

BK_ADJ

3

4

BK_ADJ

GNDC

5

6

BK_PWM_ADJ

BK_ADJ

7

8

LVDS_BKLTCTL

.
