Avalue BFC-10W7 - Manual (Page 4)

BFC-10W7
4 BFC-10W7 Quick Reference Guide
Display
Chipset Intel NM10 Express Chipset
Resolution CRT: up to 2048x1536@ 60 Hz
Dual Display CRT + LVDS with clone mode
LVDS Dual 18/24-bit LVDS
Audio
AC97 Codec Realtek ALC892 supports 5.1CH Audio
Audio Interface Line out (audio jack), AMP Line-in, Line-out, Mic-in (in header)
Mechanical & Environmental
Mounting Wall/Stand/VESA 75 mm x 75 mm
Power Input Wall/Stand/VESA 75 mm x 75 mm
Power Output 100~250 Vdc/ 47~63 Hz
Power Type AT/ATX
Operating Temp. 32 to 104°F (0 to 40°C)
Storage Temp. -14 to 140°F (-10 to 60°C)
Operating Humidity 5%~90% relative humidity, non-condensing
Dimensions 251.94mm x 154.5mm x 45.25mm
Weight 251.94mm x 154.5mm x 66.05mm (w/ HDD)
Reliability
EMI Test CE/FCC Class B
Dust and Rain Test Front side IP65
Operating Temperature 0°C ~ 40°C
Operating Humidity 0%~90% relative humidity, non-condensing
Storage Temperature -10°C ~ 60°C
