Quick Reference Guide
BFC-10W7 Quick Reference Guide 3
1.3 System Specifications
System
Board ECM-CDV
CPU Intel® Atom™ Dual-Core D2550 1.86GHz CPU
BIOS AMI 8M-bit SPI BIOS
System Chipset Intel® NM10 Express Chipset
I/O Chip Nuvoton W83627DHG-P
System Memory
One SODIMM socket supports up to 4GB DDR3 800/1066
SDRAM
SSD One CompactFlash Type I/II socket
Hard Driver Bay Optional One 2.5”HDD or SSD (Total height: 66.05mm )
WiFi Optional Mini PCIe WiFi 802.11b/g/n
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system temperature and voltage. Auto throttling
control when CPU overheats
Expansion 1 x Mini-PCIe (mSATA supported)
Panel
LCD size 10.1", 16:9
Display type LED
Resolution 1024 x 600
Pixel pitch 0.2175 (H) x 0.2088 (V)
Luminance 200 cd/m²
Contrast ratio 500
Viewing angle 20(U), 45(D), 45(L), 45(R )
Response time 25 ms
Backlight LED Backlight
Touch Type Projected Capacitive Touch
Touch Light
Transmission
86%
Touch Interface USB
Rear I/O
Serial Port 1 x RS232, 1x RS232/422/485 (selected by jumper)
Ethernet 2 x RJ-45 (Dual Intel 82574L Gigabit Ethernet)
VGA 1 x HDMI & 1 x VGA
Audio port 1 x Mic in
USB 3 x USB
Speaker 2 x 2W (or optional Line out x 1)
