Avalue FPC-08W27 User Manual
Page 6
FPC-08W2x Series
6 FPC-08W2x Series Quick Reference Guide
Rear Panel I/O
Serial Port
1 x RS-232, 1 x RS-232 or optional RS-422/485
Ethernet
Dual Realtek RTL8101L LAN
Dual Marvell 88E8053 GigaLAN
WIFI
Optional USB WiFi 802.11 b/g
(occupy one USB port)
Optional USB WiFi 802.11 b/g
VGA
1 x DB-15
HDMI
n/a
n/a
Audio
Line out, Mic in
(Realtek ALC203)
Line out, Mic in
(Realtek ALC655)
USB
2 x USB 2.0
4 x USB 2.0
Mouse & KB
1 x PS/2 Keyboard connector
n/a
Mechanical & Evironmental
Color
Front panel Black
Rear panel Black
System Power Requirement
+12V ~ +20V power input
+12V single power input
Power Adapter
Input: 100~250 Vdc/ 47~63 Hz; Output: +12 Vdc / 5 A (60W)
Operating Temperature
-10°C to 60°C
0°C to 40°C
Storage Temperature
-20°C to 70°C
-10°C to 50°C
Relative Humidity
10% to 95% @ 40°C, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm
Dimensions
225 x 129 x 40.4 mm
Weight
1.26 Kgs
