Quick Reference Guide
FPC-08W2x Series Quick Reference Guide 5
1.3 System Specifications
Panel
Specifications FPC-08W21 FPC-08W24
LCD size 8"
Display type WSVGA TFT
Resolution 1024x600
Color 256K
Pixel pitch 0.1725mm(H) x 0.1656mm(V)
Luminance 500 cd/m²
Contrast ratio 700
Viewing angle 2X
Response time 20 ms
Backlight LED
Touch Type 5-wire Resistive
Touch Light Transmission 80%
Touch Interface
USB onboard Touch Controller
PenMount 6000
USB Touch Control Board EETI
System
Board ECM-LX800D ECM-945GSE
CPU
Onboard AMD Geode LX800 @ 0.9
W 500 MHz with 128K L2 cache
Intel® Atom processor N270 1.6GHz
CPU
Cooling Method Passive CPU heatsink
System Chipset AMD Geode LX800/CS5536 Intel® 945GSE / ICH7-M
I/O Chip Winbond W83627HG-AW ITE IT8712F
Memory Onboard 512MB DDR Memory
One 200-pin SODIMM socket supports
up to 2GB DDR2 400/533MHz
SDRAM
SSD
One CF socket by IDE secondary slave channel supports Type I / II Compact
Flash Card
Mouse & KB 1 x PS/2 Keyboard connector n/a
