Quick Reference Guide
EMS-BYT Series Quick Reference Guide 33
2.5.4 AUX-M07
Connectors
Label Function Note
USB1~2 USB connector 1~2
COM3~6 Serial port connector 3~6
SJP2 SMBUS of TCA9555 address setting 3 x 2 header, pitch 2.00mm
2.5.5 EBM-BYTS DB-A
Jumpers
Label Function Note
OJRI3/4 COM 3/4 pin 9 signal select 3 x 2 header, pitch 2.00mm
Connectors
Label Function Note
OUSB1~2 USB connector 1~2
LAN2~3 LAN connector 2~3
COM3~4 Serial port connector 3~4
HDMI1 HDMI connector 3 x 2 header, pitch 2.00mm
OJP485 Serial port 1/ 2
– RS485 mode select
6 x 2 header, pitch 2.00mm
OJP1 SMBUS of TCA9555 address setting 3 x 2 header, pitch 2.00mm
2.5.6 EBM-CDVS DB-A
Connectors
Label Function Note
USB1~2 USB connector 1~2
PWRBTN Power button
LED_PWR LED Power
LED_HDD LED HDD
CN1 Front Panel connector 1 5 x 1 wafer, pitch 2.00 mm
DVI1 DVI connector
