2.1 ERS-A50M connector list
Connectors
Label Function Note
COM1~2 Serial port connector1~2
DC-IN Lockable DC Jack
HDD HDD Indicator
PWR Power Indicator
LAN1 RJ-45 Ethernet 1
LAN2 RJ-45 Ethernet 2
LINE IN Line-in audio jack
LINE OUT Line-out audio jack
MIC IN Microphone-in audio jack
Power System power switch
HDMI HDMI connector
COMPACT FLASH CF card connector
USB1~6 USB connector 1~6
