Quick Reference Guide
ERS A50M Quick Reference Guide 5
1.3 System Specifications
Specifications
System
CPU AMD® eOntario T56N 1.6GHz CPU
BIOS AMI 32 Mbit SPI BIOS
System Chipset AMD A50M Chipset
I/O Chip Winbond W83627DHG-P
System Memory One 204-pin DDR3 SODIMM up to 4GB DDR3-1066 SDRAM
SSD 1 x CompactFlash Type I/II Socket
Hard Disk 1 x 2.5” SATA HDD
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status
Monitor
Monitoring System Temperature, Voltage.
Auto Trotting Control When CPU Overheats
External I/O
COM Port 2 x RS232 (COM2 can be set as RS-422/485 by BIOS and conformable cable)
LAN Port 2 x RJ45
Antenna
2 Knockouts for Antenna Mounting
(Options to Add WiFi & 3G)
VGA 1 x VGA
HDMI 1 x HDMI
Audio Port Mic in, Line-in and Line out
USB Port 6 x USB 2.0 (Rear 5; Front 1)
Expansions 1 Mini-PCIe Socket (mSATA supported)
Display
Chipset AMD Radeon 6320
Resolution VGA: 2560 x 1600 @ 75 Hz , HDMI: 1920x1200 @75Hz
Audio
Audio Chipset Realtek ALC892 supports 7.1-CH Audio
Audio Interface Mic in, Line-in and Line-out
Ethernet
LAN Chip 2x Realtek 8111E GigaLAN, supports Wake on LAN
Ethernet Interface 10/100/1000Base-Tx Fast Ethernet compatible
Mechanical &
Environmental
Power Requirement +12 ~ +26Vdc (Lockable DC Jack)
ACPI Single Power ATX Support S0, S1, S3, S4, S5 and ACPI 3.0 Compliant
Power Type AT/ ATX
