Quick Reference Guide
ASM-CDV Quick Reference Guide 5
1.3 System Specifications
System
Board EBM-CDV
CPU Onboard Intel® Atom™ D2550 1.86GHz CPU
BIOS AMI 16Mbit SPI BIOS
System Chipset Intel® NM10 Express Chipset
System Memory One 204-pin SODIMM Supports Up to 4GB DDR3 1066MHz SDRAM
SSD One CompactFlash Type I/II Socket
Audio Realtek ALC892 Support 5.1-CH Audio
Ethernet Dual Intel® 82574L Gigabit Ethernet
System Indicators 4 LED Indicators Show Power and HDD Status
Drive Bay Mounting Kit for One 2.5” SATA HDD/ SSD (Hidden)
Expansion Interface 1 x Mini PCIe Slot (mSATA Supported)
External I/O
COM 2 x RS-232 (COM2 RS-232/422/485 Setting by JP & SW)
LAN 2 x RJ-45
WiFi 1 Knockouts for Antenna Mounting
VGA 1 x VGA
HDMI 1 x HDMI
Audio 1 x Mic-in, 1 x Line-in, 1 x Line-out
USB 4 x USB 2.0 (Rear 2; Front 2)
Power Supply Unit
Power Input 100 ~ 240Vac/ 50 ~ 60Hz
Power OutPut +12Vdc/ 5A (60W)
Environmental
Power Requirement +12Vdc ~ +26Vdc (Lockable DC Jack)
Operating Temperature 0 ~ 50°C (32 ~ 122°F)
Storage Temperature -40 ~ 75°C (-40 ~ 167°F)
Relative Humidity 0% ~ 90% Relative Humidity, Non-condensing
Vibration Protection With CF/ SSD: 1.5Grms, IEC 60068-2-64, Random,
5 ~ 500Hz, 30min/axis
Shock Protection With CF/ SSD: 10G, IEC 60068-2-27, Half Sine,11ms
Dimension (W x D x H) 7.2” x 10.1” x 1.0” (182mm x 257mm x 25mm)
Weight 3.3lbs (1.5Kgs)
Mounting VESA 100 & 75
