Avalue ASM-CDV User Manual
Page 12
ASM-CDV
12 ASM-CDV Quick Reference Guide
Step 5-3. Insert the HDD into the Drive Bay. Remember
to properly seat the HDD so as to match screws and
HDD holes.
Step 6. Reassemble the top chassis and
fasten with 3 screws.
Step 7.
Fasten 4 screws from the bottom chassis.
Step 8. Reassemble the rear chassis and
fasten 3 screws to lock.
